Grade 80 Clevis Self Locking Hook
The latch on this hook automatically closes when pulling force is applied to the sling
Designed to attach directly to a length of chain via the engineered clevis head
This engineered head prevents hook to chain mismatch
Grade 80 alloy steel
4:1 design factor
Tough powder coat finish
Replacement parts always available
Proof tested and certified
Parameter
|
FOR
CHAIN SIZE |
WORKING
LOAD LIMIT (lbs.) |
A
(in) |
B
(in) |
C
(in) |
G
(in) |
H
(in) |
R
(in) |
T(in)
|
PxL(in)
|
|---|---|---|---|---|---|---|---|---|---|
|
9/32-5/16″
|
4,500
|
1.34
|
0.35
|
0.39
|
0.79
|
1.02
|
4.84
|
1.69
|
0.35×0.89
|
|
3/8″
|
7,100
|
1.77
|
0.47
|
0.55
|
0.98
|
1.18
|
5.63
|
2.2
|
0.51×1.24
|
|
1/2″
|
12,000
|
2.01
|
0.59
|
0.67
|
1.38
|
1.57
|
7.08
|
2.72
|
0.63×1.65
|
|
5/8″
|
18,100
|
2.36
|
0.75
|
0.75
|
1.42
|
1.97
|
8.46
|
3.15
|
0.83×2.03
|
|
3/4″
|
28,300
|
3.94
|
0.98
|
0.87
|
2.01
|
2.48
|
9.25
|
3.46
|
0.94×2.42
|
Standards
Name: Grade 80 Clevis Self Locking Hook
Package: Carton + Steel Pallet
